Name: 40Gb/s LX4 QSFP+ 2km Transceiver Duplex LC SMF/MMF Digital Diagnostics Monitoring
Brand: Shenzhen HiLink Technology Co.,Ltd.
SKU: HL-QSFP-40G-LX4
Price: 81.00 USD
Availability: InStock

Casa. > prodotti > Ricetrasmettitore di QSFP+ >

40Gb/s LX4 QSFP+ 2km Transceiver Duplex LC SMF/MMF Digital Diagnostics Monitoring

1270~1330nm QSFP+ Transceiver

4 CWDM Lanes MUX/DEMUX Optical Module

2km Fiber Optic Transceiver

Luogo di origine:

Guangdong, Cina

Marca:

HILINK

Certificazione:

CE FCC Rohs

Numero di modello:

HL-QSFP-40G-LX4

Contattaci

Chiedi un preventivo

40Gb/s LX4 QSFP+ 2km Transceiver Duplex LC SMF/MMF Digital Diagnostics Monitoring

Dettagli del prodotto

Nome dei prodotti:

40GQSFP+2Km

Connetor:

Duplex lc

Velocità dati:

40g

Distanza:

2 km

Intervallo di temperatura:

0°C ~ +70°C

Certificazione:

RoHS Compliant

Tipo:

Transocivisti in fibra ottica, 40G QSFP+

Funzioni diagnostiche digitali:

Incorporato

Termini di pagamento e di spedizione

Quantità di ordine minimo

1pcs

Prezzo

EXW: 75~87USD/PCS

Imballaggi particolari

La borsa statica, il piano di plastica, scatola al minuto, da richiede

Tempi di consegna

5-8workingdays

Termini di pagamento

Western Union, T/T, L/C

Capacità di alimentazione

100 pezzi/mese

Prodotti correlati

40G QSFP+ SWDM4 Optical Transceiver with 240m/350m Distance Duplex LC Connector and Built-in Digital Diagnostics

Ottenga il migliore prezzo

40Gb/s 150m QSFP+ SR4 Transceiver Modulo in fibra ottica MPO Connector

Ottenga il migliore prezzo

Modulo in fibra ottica QSFP+ 40Gb/s 100m Bi-Di Duplex LC Hot Pluggable 850/900nm MMF

Ottenga il migliore prezzo

40Gb/s 60km QSFP+ Trasmettitore Hot Pluggable Duplex LC Connector Single mode

Ottenga il migliore prezzo

Contattaci

86-755-8317-6243

Contatta ora

Descrizione del prodotto

40Gb/s LX4 QSFP+ 2km Transceiver Duplex LC SMF/MMF Digital Diagnostics Monitoring

Product Description

40Gb/s LX4 IR4 QSFP+ 2km Transceiver Duplex LC SMF/MMF Digital Diagnostics Monitoring

Key Features

Up to 11.2Gbps per channel bandwidth
Aggregate bandwidth of > 40Gbps
Duplex LC connector
Compliant with 40G Ethernet IEEE802.3ba and 40GBASE-SR4/IR4 Standard
QSFP MSA compliant
Maximum link length of 100m on OM3 and 150m on OM4
4 CWDM lanes MUX/DEMUX design
Compliant with QDR/DDR Infiniband data rates
Single +3.3V power supply operating
Built-in digital diagnostic functions
Operating temperature range: 0°C to 70°C
RoHS Compliant

Applications

Rack to rack connections
Data center switches and routers
Metro networks
40G Ethernet links

Technical Details

The HL-QSFP-40G-LX4 transceiver module is designed for 2km (SMF) and 150m (MMF) optical communication applications. Compliant with 40GBASE-SR4 and 40GBASE-LX4 of the IEEE P802.3ba standard, it converts 4 input channels of 10Gb/s electrical data to 4 CWDM optical signals, multiplexing them into a single channel for 40Gb/s optical transmission. On the receiver side, it optically de-multiplexes a 40Gb/s input into 4 CWDM channel signals and converts them to 4 channel output electrical data.

Our Services

We offer OEM and ODM services for custom orders.

Quality Guarantee

All optical transceivers are brand new with new components, never using old or refurbished materials. Each unit undergoes functional and aging tests. We provide a 3-year warranty from the date of shipment.

Product Range

We supply compatible optical transceiver modules including SFP, GBIC, SFP+, XENPAK, X2, XFP, BIDI, CWDM, DWDM and other special modules compatible with most major brands.

Packaging & Shipping

We ship internationally via DHL, FedEx, EMS, TNT, UPS with delivery in 3-7 days.
